Chihai DC11.1V 31000rpm High Torque Motor DC Gear Motor

Reference: BG0052-9993042

Condition: New product

100 Item Items Warning: Last items in stock!

$39.55

Quantity

Description:

Chihai M90-M150 DC11.1V 31000rpm Torque Motor Blue Short Shaft Motor

Specifications:

No load speed	No load current	At stall torque	At stall torque
31000 rpm	3.5 A	5712.9 g.cm	189.500 A

At Maximum Efficiency

Speed	Current	Torque	Output	EFF.
27280.0 rpm	25.820 A	685.5 g.cm	191.811W	66.93%

At Maximum Output

Speed	Current	Torque	Output	EFF.
15500 rpm	96.500 A	2856.4 g.cm	454.099 W	42.39%

Features:

1. pure copper wire winding
The rotor part adopts pure copper group, small resistance, strong conductivity, and makes motor torque increase.

2. CNC aluminum alloy rear cover housing
High strength, high accuracy, fast heat dissipation and strong corrosion resistance.

3. D type shaft with D hole gear
The D type shaft is more convenient to install, not easy to skid and enhance the twisting force.

4. hollowed out shell structure
Increase internal heat dissipation, reduce operating temperature and improve load characteristics.

5. Frequent blocking or frequent start-up and reversal are not recommended in the use process, which will greatly reduce the service life.

Package Included:

1×	Blue Short Shaft Motor

More Details:

Chihai-DC111V-31000rpm-High-Torque-Motor-DC-Gear-Motor-1730442
